锂电池充电芯片，SOT23-5封装，贴片五脚芯片规格书：
GENERAL DESCRIPTION
The PW4055 is a complete constant-current /constant-voltage linear charger for single cell lithiumion batteries.Its ThinSOT package and low external component count make the PW4055 ideally suited for portable applications.Furthermore, the PW4055 is specifically designed to work within USB power specifications.
The PW4055 No external sense resistor is needed, and no blocking diode is required due to the internal MOSFET architecture.Thermal feedback regulates the charge current to limit the die temperature during high power operation or high ambient temperature. The charge voltage is fixed at 4.2V, and the charge current can be programmed externally with a single resistor. The PW4055 automatically terminates the charge cycle when the charge current drops to 1/10th the programmed value after the final float voltage is reached. When the input supply (wall adapter or USB supply) is removed, the PW4055 automatically enters a low current state, dropping the battery drain current to less than 2µA. The PW4055 can be put into shutdown mode, reducing the supply current to 25µA.
The BAT pin has a 7KV ESD(HBM) capability. Other features include charge current monitor, undervoltage lockout, automatic recharge and a status pin to indicate charge termination and the presence of an input voltage.
FEATURES
⚫ Programmable Charge Current Up to500mA
⚫ Complete Linear Charger in ThinSOT Package for single Cell Lithium-Ion Batteries
⚫ Constant-Current/Constant-Voltage Operation with Thermal Regulation to Maximize Charge Rate Without Risk of Overheating
⚫ Charges Single Cell Li-Ion Batteries Directly from USB Port
⚫ Charge Current Monitor Output for Gas Gauging
⚫ Automatic Recharge
⚫ Charge Status Output Pin
⚫ C/10 Charge Termination
⚫ Soft-Start Limits Inrush Current
⚫ 7KV ESD(HBM) capability
APPLICATIONS
⚫ Cellular Telephones, PDAs, MP3 Players
⚫ Charging Docks and Cradles
⚫ Bluetooth Applications
